Brand Name : GENWELD
Model Number : LWG-1000
Certification : CE
Place of Origin : CHONGQING
MOQ : 50 sets
Payment Terms : T/T, L/C
Supply Ability : 10000 sets per month
Delivery Time : 30 work days
Packaging Details : Seaworthy carton 390*185*340mm
Application : Civil steel structure maintenance
GENWELD LWG-250 150A Portable Civil-purpose MMA Inverter Welder
Specifications sheet
| Equipment overview | |
| Rated input power | Single-phase 380/220V±5%/50Hz |
| environmental needs | Temperature 5-40℃, humidity 10-90% |
| Laser wavelength | 1080nm |
| modulation frequency | 20KHZ |
| cooling method | water cooling |
| light speed output | 1 beam |
| Maximum power consumption | 5.5KW |
| Water cooler parameters | |
| Power system | 220V±5%,50Hz 40A |
| Cooling water flow | 8L/min |
| Chiller size | 60*30*47 |
| Cooling capacity | 5200W |
| Laser water cooling temperature range | 2-50℃ |
| The refrigerant | R22 / 2kg |
| Fiber parameters | |
| Core diameter | 100um |
| length | 15m |
| Maximum bending radius | 200mm |
| jacket | 金属包塑护管 |
| interface | QBH |




|
|
GENWELD LWG-1000 Portable Handheld Laser Cleaning Machine Images |
